View cloud services

Note:

ColdFusion 2021 Performance Monitoring Toolset can be used with ColdFusion (2018 release) for monitoring. However, few features like Cloud Services, NoSQL, etc. cannot be monitored. To use these, you must upgrade to ColdFusion (2021 release).

Overview

To enable monitoring for various cloud services, in Settings, enable the following options:

  • Cloud services monitoring.
  • Enable tag / function monitoring
Cloud services monitoring option
Cloud services monitoring option

On the Overview page of Cloud services, you can see an overview of all the cloud services that you’ve worked on.

You can see the ARTs as a line graph segmented by the cloud services and the API invoke times as a density chart segmented by the services.

Also, you can see a table of what services were used the most.

S3

Monitoring is an important part of maintaining the reliability, availability, and performance of Amazon S3 and your AWS solutions. You should collect monitoring data from all of the parts of your AWS solution so that you can more easily debug a multipoint failure if one occurs.

When you, for example, create an S3 bucket, and insert an object in the bucket, Performance Monitoring Toolset records the transaction, and shows the metrics, like, ART as charts.

You can monitor up to five buckets at a time.

From the Buckets drop-down list, choose a bucket, and view its metrics.

Average Response Time

Displays a time series chart of all the S3 operations executed within a time window.

ART of S3 service
ART of S3 service

API Invocation

Displays the number of API calls as a time-series graph.

Throughput of S3 service
API call count of S3 service

Other visualizations

Apart from ART and API calls, these are the other charts that you can view for the service:

  • Top slow operations of the service
  • Number of S3 buckets
  • Number of S3 objects
  • Number of S3 methods called
  • Distribution of status

Azure Blob

To see all metrics, you can create containers, and upload blobs in each. You can see the metrics for each container.

You can monitor up to five containers at a time.

From the drop-down, choose a container, and view its metrics.

Average Response Time

Displays a time series chart of all the Blob operations executed within a time window.

ART of Azure Blob
ART of Azure Blob

API Invocation

Displays the number of API calls as a time-series graph.

Throughput of Azure Blob service
API call count

Other visualizations

Apart from ART and API calls, these are the other charts that you can view for the service:

  • Top slow operations of the service
  • Number of containers
  • Number of objects
  • Number of blob methods called
  • Distribution of status

AWS SQS

To see all metrics, you can create queues, and send messages in each. You can see the metrics for each queue.

You can monitor up to five queues at a time.

From the Queues drop-down, choose a queue, and view its metrics.

Average Response Time

Displays a time series chart of all the SQS operations executed within a time window.

ART of Amazon SQS
ART of Amazon SQS

API Invocation

Displays the number of API calls as a time-series graph.

Throughput of Amazon SQS
API call count of Amazon SQS

Other visualizations

Apart from ART and API calls, these are the other charts that you can view for the service:

  • Top slow operations of the service
  • Number of queues
  • Number of SQS methods called
  • Distribution of status

Amazon SNS

To see all metrics, you can create topics, and create subscriptions in each. You can see the metrics for each topic.

You can monitor up to five topics at a time.

From the Topic drop-down, choose a topic, and view its metrics.

Average Response Time

Displays a time series chart of all the SNS operations executed within a time window.

ART of Amazon SNS
ART of Amazon SNS

API Invocation

Displays the number of API calls as a time-series graph.

Throughput of Amazon SNS
API call count of Amazon SNS

Other visualizations

Apart from ART and API calls, these are the other charts that you can view for the service:

  • Top slow operations of the service
  • Number of topics
  • Number of subscriptions
  • Number of SNS methods called
  • Distribution of status

Azure Service Bus

To see all metrics, you can create queues, and send messages in each. You can see the metrics for each queue.

You can monitor up to five queues at a time.

From the filters, choose a queue or a topic, and view its metrics.

Average Response Time

Displays a time series chart of all the Service Bus operations executed within a time window.

ART of Azure Service Bus
ART of Azure Service Bus

API Invocation

Displays the number of API calls as a time-series graph.

Throughput of Azure Service Bus
API invocation of Azure Service Bus

Other visualizations

Apart from ART and API calls, these are the other charts that you can view for the service:

  • Top slow operations of the service
  • Number of topics/queues
  • Number of Service Bus methods called
  • Distribution of status

AWS DynamoDB

Average Response Time

Displays a time series chart of all the DyanmoDB operations executed within a time window.

ART of Dynamo DB
ART of Dynamo DB

API Invocation

Displays the number of API calls as a time-series graph.

Throughput of Dynamo DB
API call count of Dynamo DB

Other visualizations

Other visualizations of Dynamo DB
Other visualizations of Dynamo DB
