After you create a symbol, you can create instances of that symbol throughout your document, including inside other symbols. When you modify the symbol, Animate CC (formerly Flash Professional CC) updates all instances of the symbol.
You can give names to instances from the Property inspector. Use the instance name to refer to an instance in ActionScript. To control instances with ActionScript®, give each instance within a single timeline a unique name.
To specify color effects, assign actions, set the graphic display mode, or change the behavior of new instances, use the Property inspector. The behavior of the instance is the same as the symbol behavior, unless you specify otherwise. Any changes you make affect only the instance and not the symbol.
Select a layer in the Timeline. Animate can place instances only in keyframes, always on the current layer. If you don’t select a keyframe, Animate adds the instance to the first keyframe to the left of the current frame.
A keyframe is a frame in which you define a change in the animation. For more information, see Insert frames in the Timeline.
Each symbol instance has its own properties that are separate from the symbol. You can change the tint, transparency, and brightness of an instance; redefine how the instance behaves (for example, change a graphic to a movie clip); and specify how an animation plays inside a graphic instance. You can also skew, rotate, or scale an instance without affecting the symbol.
In addition, you can name a movie clip or button instance so that you can use ActionScript to change its properties. For more information, see Objects and classes in Learning ActionScript 3.0. To edit instance properties, you use the Property inspector (Windows > Properties).
The properties of an instance are saved with it. If you edit a symbol or relink an instance to a different symbol, any instance properties you’ve changed still apply to the instance.
You can make a symbol instance on the Stage invisible by turning off the Visible property. Using the Visible property provides faster rendering performance than setting the symbol’s Alpha property to 0.
The Visible property requires a Player setting of Flash Player 10.2 or later and is only compatible with movie clip, button, and component instances.
Each instance of a symbol can have its own color effect. To set color and transparency options for instances, use the Property inspector. Settings in the Property inspector also affect bitmaps placed in symbols.
When you change the color and transparency for an instance in a specific frame, Animate makes the change as soon as it displays that frame. To make gradual color changes, apply a motion tween. When tweening color, you enter different effect settings in starting and ending keyframes of an instance, and then tween the settings to make the instance’s colors shift over time.
If you apply a color effect to a movie clip symbol that has multiple frames, Animate applies the effect to every frame in the movie clip symbol.
In the Property inspector, select one of the following options from the Style menu in the Color Effect section:
Adjusts the relative lightness or darkness of the image, measured on a scale from black (–100%) to white (100%). To adjust brightness, click the triangle and drag the slider or enter a value in the box.
Colors the instance with the same hue. To set the tint percentage from transparent (0%) to completely saturated (100%), use the Tint slider in the Property inspector. To adjust tint, click the triangle and drag the slider or enter a value in the box. To select a color, enter red, green, and blue values in the respective boxes, or click the Color control and select a color from the Color Picker.
Adjusts the transparency of the instance, from transparent (0%) to completely saturated (100%). To adjust the alpha value, click the triangle and drag the slider or enter a value in the box.
Separately adjusts the red, green, blue, and transparency values of an instance. This is most useful to create and animate subtle color effects on objects such as bitmaps. The controls on the left let you reduce the color or transparency values by a specified percentage. The controls on the right let you reduce or increase the color or transparency values by a constant value.
The current red, green, blue, and alpha values are multiplied by the percentage values, and then added to the constant values in the right column, producing the new color values. For example, if the current red value is 100, setting the left slider to 50% and the right slider to 100% produces a new red value of 150 ([100 x .5] + 100 = 150).
note: The Advanced settings in the Effect panel implement the function (a * y+ b)= x where a is the percentage specified in the left set of boxes, y is the color of the original bitmap, b is the value specified in the right set of boxes, and x is the resulting effect (between 0 and 255 for RGB, and 0 and 100 for alpha transparency).
You can also change the color of an instance using the ActionScript ColorTransform object. For detailed information on the Color object, see ColorTransform in ActionScript 2.0 Language Reference or ActionScript 3.0 Language and Components Reference.
To display a different instance on the Stage and preserve all the original instance properties, such as color effects or button actions, assign a different symbol to an instance.
For example, suppose you are creating a cartoon with a rat symbol for your character, but decide to change the character to a cat. You could replace the rat symbol with the cat symbol and have the updated character appear in roughly the same location in all your frames.
To redefine an instance’s behavior in a Animate application, change its type. For example, if a graphic instance contains animation that you want to play independently of the main Timeline, redefine the graphic instance as a movie clip instance.
To determine how animation sequences inside a graphic instance play in your Animate application, set options in the Property inspector.
An animated graphic symbol is tied to the Timeline of the document in which the symbol is placed. In contrast, a movie clip symbol has its own independent Timeline. Animated graphic symbols, because they use the same Timeline as the main document, display their animation in document-editing mode. Movie clip symbols appear as static objects on the Stage and do not appear as animations in the Animate editing environment.
Fame Picker helps you to visually preview and choose the first frame for a graphic symbol. In previous releases, you could not preview the frames without getting within the symbol in Edit mode. This feature enhances user experience for animation workflows such as Lip-Sync.
Frame Picker panel works only with graphic symbols and is disabled for movie clip or button symbol types. Ensure that you have converted your assets to symbols before you work with this feature.
In the Frame Picker panel, select List or Thumbnail view to display all the frame previews of the selected graphic symbol. You can also view the frame numbers and their labels.
List Displays the frames in a vertical list view.
Thumbnail Displays frames are in grid view and re-adjusts when the panel is resized.
Create Keyframe This option enables you to create a Keyframe automatically when you select a position from the framepicker panel.
Loop Displays the various looping options for graphics such as Loop, Play once, and Single frame.
Slider arrow Adjusts preview size
Slider left button Fits more frames in view
Slider right button Fits less frames in view
Filter frame options dropdown Displays the various filter frame options
Frame Picker panel offers a Create Keyframe check box that allows automatic creation of Keyframes when selecting a frame in the Frame Picker panel. You can also set looping option of Graphic symbols from within the Frame Picker panel.
You can invoke the Frame Picker panel by selecting a Graphic symbol > Properties Panel > Looping > Use Frame Picker button to display the Frame Picker or by selecting Window > Frame Picker.
Animate offers filtering options for the frames listed in the panel. You can choose to filter by,
- All Frames - displays all the frames.
- Keyframes - displays only key frames as selected by you.
- Labels - displays only frames with labels.
Auto lip-syncing allows easier and faster method of placing appropriate mouth shapes on Timeline, based on the chosen audio layer. You can achieve this using an existing list of mouth poses, drawn within a graphic symbol. When you apply auto lip-syncing on a graphic symbol, key-frames are created automatically at different positions matching with the audio visemes, after analyzing the specified audio layer. Once completed, you can make any further adjustments if needed, by using regular workflows and Frame Picker.
A viseme is a generic facial image that can be used to indicate a sound.
To break the link between an instance and a symbol and make the instance into a collection of ungrouped shapes and lines, you break apart the instance. This feature is useful for changing the instance substantially without affecting any other instance.
Changes to the source symbol for an instance do not affect an instance after it has been broken apart.
The Property inspector and Info panel display the following information about instances selected on the Stage:
In the Property inspector, view the instance’s behavior and settings—for all instance types, color effect settings, location, and size; for graphics, the loop mode and first frame that contains the graphic; for buttons, the instance name (if assigned) and tracking option; for movie clips, the instance name (if assigned). For location, the Property inspector displays the x and y coordinates of the symbol’s registration point.
In the Info panel, view the instance’s size and location; the location of its registration point; its red (R), green (G), blue (B), and alpha (A) values (if the instance has a solid fill); and the location of the pointer. The Position and Size section on the Properties Inspector displays the x and y coordinates of either the symbol’s registration point or transformation point. You can toggle to view coordinates of either the registration point or transformation point.
In the Movie Explorer, view the contents of the current document, including instances and symbols.
View any actions assigned to a button or movie clip in the Actions panel.
