BnW Spots 3 | Substance 3D Designer

BnW Spots 3

BnW Spots 3

In: Texture Generators/Noises

Simple

Description

This node generates a multi-frequency noise with nice details in both large, medium and small scales. Nr 3 has less options than Nr 1, and less contrast and small frequency details than Nr 2, resulting in a more even scale with less peaks and valleys.

Parameters

  • Scale: 1 - 8
    Sets the global scale for the effect.
  • Disorder: 0.0 - 1.0
    Phase-shifts the noise to introduce small variation.
  • Non Square Expansion: False/True
    Enables compensation of squash and stretch with non-square ratios.

Example Images
