Cells 2

Cells 2

In: Texture Generators/Noises

Simple

Description

Generates a Worley Voronoi-type noise, with simple Euclidean distance metric, similar to Cells 1, but with hard instead of soft transition between the cells..

It works well as a simple base noise for Cracks, geometric or shattering effects. A similar result can be achieved with the Distance atomic node.

Parameters

  • Scale: 1 - 256
    Sets the global scale for the effect.
  • Edge Width: 0.0 - 4.0
    Controls the thickness of the edges between cells.
  • Invert: False/True
    Inverts the result.
  • Disorder: 0.0 - 1.0
    Phase-shifts the noise to introduce small variation
  • Non Square Expansion: False/True
    Enables compensation of squash and stretch with non-square ratios.

Example Images
