Directional Noise 2 | Substance 3D Designer

Directional Noise 2

Directional Noise 2

In: Texture Generators/Noises

Intermediate

Description

This generates a noise with a good spread of details and a clear directionality to it. Compared to Directional Noise 1, it has a slightly finer detail scale.

Parameters

  • Scale: 1 - 4
    Sets the global scale for the effect.
  • Disorder: 0.0 - 1.0
    Phase-shifts the noise to introduce small variation.
  • Angle: 0.0 - 1.0
    Sets the global angle for the direction.
  • Angle Random: 0.0 - 1.0
    Randomises the direction angle.
  • Non Square Expansion: False/True
    Enables compensation of squash and stretch with non-square ratios.

Example Images
